Carbon Offroad Long Drum 6000lb Winch Kit - No Hook
26m Rope Length
$699.00
RRP $769.00
SAVE $70.00 (9%)
In Stock
The Carbon Offroad Long Drum 6000lb Winch (CW-XD6L) is a compact, long-drum 6,000 lb winch fitted with a 26 m synthetic rope, sealed motor, dual remotes and fail-safe braking.
It is intended for ATVs, small 4x4s, trailers, caravans and boats where extra rope length is required.
Features:
- IP68 for winch and solenoid (excludes remotes)
- 12V DC 2.5 HP permanent magnet motor
- 3-stage planetary geartrain
- Cam action clutch for near-silent free-spooling
- Mechanical and dynamic automatic braking to prevent rollback
- Long drum design to accommodate 26 m (85.3 ft) of synthetic rope
Kit Includes:
- 1 x Carbon Offroad Long Drum 6000lb Winch (CW-XD6L)
- 1 x Synthetic Rope (26m x 6.5mm diameter)
- 1 x Aluminium Hawse Fairlead
- 1 x Handlebar Mini-Rocker Switch
- 1 x Wireless Remote Control
- 1 x Control Box complete with cables & mounting bolts
(CW-XD6L)
| Rated line pull | 6000 lbs (2725 kg) single-line |
|---|---|
| Motor | 12V DC 2.5 HP permanent magnet |
| Geartrain | 3-Stage Planetary |
| Gear ratio | 147:1 |
| Clutch | Roller disc full load automatic |
| Brake | Automatic brake in the motor bracket |
| IP rating | IP68 for winch and solenoid (excludes remotes) |
| Synthetic rope | 26m x 6.5mm (85.3 ft x 1/4") |
| Drum dimensions | 51mm x 208mm (2.0" x 8.2") |
| Mounting bolt pattern | 254mm x 76mm (10.0" x 3.0") |
| Recommended battery | 650 CCA minimum for winching |
| Winch dimensions (L x W x H) | 473 x 125 x 120mm (18.6" x 4.9" x 4.7") |
| Packing dimensions (L x W x H) | 530 x 170 x 230mm (20.9" x 6.7" x 9.1") |
| Winch weight (bare) | 8.3kg (18.3 lbs) with synthetic rope attached |
| Total kit weight | 11.2kg (24.7 lbs) including control box, cables, bolts & fairlead |
| Drum type | Long drum |
| Part number | CW-XD6L |
| Warranty | Lifetime Mechanical / 5 Year Electrical |
| SKU | CW-XD6L |
| Brand | Carbon Offroad |
